Mishimoto 2012-2016 BMW F22/F30 Intercooler (I/C ONLY) – Black
$815.95
-
PRODUCT DETAILS:
Make your Ultimate Driving Machine even more ultimate with the addition of this BMW 2012-2016 F22/F30 Chassis Performance Intercooler! From the factory, the N20/26 and N55 engines are a prowess of German engineering, but the stock intercooler unit poses as a weak link for your turbocharged Bimmer. The tube-and-fin design coupled with plastic end tanks makes for the perfect environment for heat to set up residence and throttle the power of your 2, 3, or 4-series, especially for those running a tune.
We’re here to unlock the full potential of your N20/26 and N55 engines with our Performance Intercooler specifically designed for the F22/F30 chassis. Our unique 6″ thick step-core design, adds a 115-degree angle to the top section to allow for additional charged air cooling without fully obstructing other heat exchangers. Tubes and fins are a thing of the past with this design as we engineered our intercooler with a bar-and-plate construction optimizing this intercooler for heat dissipation with minimal pressure drop. Coupled together, our features were able to drop intercooler outlet temperatures by 45F, and add 10 whp and 8 wtq all on the stock tune of our 2017 M2 test vehicle. The BMW F22/F30 Performance Intercooler is available in Silver or Black and also includes the Mishimoto Lifetime Warranty.
Features:
- Direct fit for the 2012-2016 BMW F22/F30 Chassis
- 6-in thick, angled step-core design optimized for maximum flow without fully obstructing other heat exchangers
- Max power gains of 10 whp and 8 wtq on stock tuning
- Drops intercooler outlet temperature by 45F on stock tuning
- Optimal core design for maximum cooling efficiency with minimal pressure drop
- Intercooler core volume increased by 96-percent
- External fin surface area increased by 130-percent
- Retains factory quick-disconnect fittings for compatibility with stock piping
- Available in silver or black
SPECIFICATIONS:
- Color: Black
- Finish: Powder-Coat
- Material: Aluminum
- Prop 65 (C, R or CR): CR
- Prop 65 Yes/No: Yes
- Applications: 2014-2016 BMW 228i/228i xDrive–2014-2016 BMW M235i/M235i xDrive–2013-2016 BMW 320i/320i xDrive–2012-2016 BMW 328i/328i xDrive–2012-2016 BMW 328d/328d xDrive–2012-2016 BMW 335i/335i xDrive–2014-2016 BMW 428i/428i xDrive–2014-2016 BMW 435i/435i xDrive–2016+ BMW M2
- Engine Codes: N20–N26–N47–N55
- Chassis Codes: F22–F23–F30–F31–F32–F33–F34–F87
- Core Type: Bar-and-Plate
- Thickness (in): 6
- Inlet (in): 2
- Outlet (in): 2
- Weight (lbs): 28
- Note: M2 owners will need to either remove or modify the front core support brace for installation. Please refer to the installation guide for proper modification instructions.
- Includes: (1) Performance Intercooler–Mishimoto Lifetime Warranty
- Installation Notes: 27 in-lbs (3NM) recommended for all T-bolt and constant-tension T-bolt clamps. These clamps have an operating range of 18-35 in-lbs (2-4NM). Do not exceed the maximum torque rating of 35 in-lbs (4NM).
FITMENT:
- 2014-2016 BMW 228i Base L4.1997cc
- 2015-2016 BMW 228i xDrive Base L4.1997cc
- 2013-2016 BMW 320i Base L4.1997cc
- 2013-2016 BMW 320i xDrive Base L4.1997cc
- 2014-2016 BMW 328d Base L4.1997cc
- 2014-2016 BMW 328d xDrive Base L4.1997cc
- 2012-2016 BMW 328i Base L4.1997cc
- 2012-2013 BMW 328i Base L6.2996cc
- 2014-2016 BMW 328i GT xDrive Base L4.1997cc
- 2013-2016 BMW 328i xDrive Base L4.1997cc
- 2013 BMW 328i xDrive Base L6.2996cc
- 2012-2015 BMW 335i Base L6.2979cc
- 2014-2016 BMW 335i GT xDrive Base L6.2979cc
- 2012-2015 BMW 335i xDrive Base L6.2979cc
- 2012-2013 BMW 335is Base L6.2979cc
- 2014-2016 BMW 428i Base L4.1997cc
- 2015-2016 BMW 428i Gran Coupe Base L4.1997cc
- 2014-2016 BMW 428i xDrive Base L4.1997cc
- 2015-2016 BMW 428i xDrive Gran Coupe Base L4.1997cc
- 2014-2016 BMW 435i Base L6.2979cc
- 2015-2016 BMW 435i Gran Coupe Base L6.2979cc
- 2014-2016 BMW 435i xDrive Base L6.2979cc
- 2015-2016 BMW 435i xDrive Gran Coupe Base L6.2979cc
- 2016-2018 BMW M2 Base L6.2979cc
- 2014-2016 BMW M235i Base L6.2979cc
- 2015-2016 BMW M235i xDrive Base L6.2979cc
Due to the nature of these items, no returns, only exchanges for defective items.
| Weight | 34 lbs |
|---|---|
| Dimensions | 35.3 × 18 × 13.2 in |
